120W Industrial Power Adapter 48V 2.5A Din Rail Wide AC/DC Input CE UL Listed

  • 1
  • 2
  • 3

Brand Name : Olycom

Model Number : IMD-DC48V2.5A

Certification : CE RoHS FCC ISO9001

Place of Origin : Shenzhen, China

MOQ : 1pc

Price : negotiable

Payment Terms : T/T, PayPal

Supply Ability : 1500Pcs per month

Delivery Time : 4~8 working days

Packaging Details : 1pc in a carton, 0.5kg/pc gross weight

Product Name : 120W Din rail power supply

Voltage output : DC47.0-DC53.0

Efficiency : 94%

Voltage Input : AC/DC wide input

DC OK Function : Support

Temperature Range : 40℃ to +70℃

Contact Now

AC/DC 120W DIN-Rail Power Supply

Key Features of 48V Power Adapter

  • Universal 85 - 264VAC or 120 - 370 VDC Input voltage
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range: -40℃ to +70℃
  • High efficiency up to 94%, high reliability
  • DC OK function
  • Active PFC
  • 150% peak load output for 3 seconds
  • DC ON output status indicator LED
  • Output short circuit, over-current, over-voltage, over-temperature protection
  • Operating altitude up to 5000m
  • OVCⅡ
  • Indoor use
  • Safety according to IEC/UL/BS EN 62368

Technical Data of 120W Power Supply

Output Power
Output Voltage Range +48-53V
Load Current 2.5A
Voltage Accuracy ±1%
Line Regulation ≤±0.5%
Load Regulation ≤±1%
Temp. coefficient ±0.03%/℃
Efficiency (%) 94%(Typ.)
Output Power 120W
Input Power
Input Voltage Range 85-264VAC
Rated Input Voltage 220VAC
Input Frequency (Hz) 47~63Hz
Input Current(MAX) ＜3A
Inrush Current <30A@220VAC
Efficiency (%) 94%(Typ.)
Environmental. Mechanical
Operating temperature -40℃～+70℃
Storage temperature -40℃～+85℃
Humidity 0~95% non-condensing, non-operating
0~90% non-condensing, operating
Leakage current ≤0.5mA@220VAC
MTBF Min300,000h
Over power protection 150% rated power, automatic recovery
Over voltage protection ≤60V, automatic recovery
Short circuit protection Long-term, automatic recovery< 10s

Introduction

  • IMD-DC48V2.5A is a din rail power adapter which can power for industrial fiber switch or industrial POE fiber switch.
  • It converts AC220V to 48V.
  • The reliable industrial grade design could ensure continuous and stable operation of the automation system.

Mechanical Information

120W Industrial Power Adapter 48V 2.5A Din Rail Wide AC/DC Input CE UL Listed

  • Case Material: Metal (AL5052, SPCC, SGCC)
  • Dimensions: 110.00 x 32.00 x 124.00 mm
  • Weight: 490g±10% (Typ.)
  • Cooling Method: Free air convection
120W Industrial Power Adapter 48V 2.5A Din Rail Wide AC/DC Input CE UL Listed
Product Photos
120W Industrial Power Adapter 48V 2.5A Din Rail Wide AC/DC Input CE UL Listed
120W Industrial Power Adapter 48V 2.5A Din Rail Wide AC/DC Input CE UL Listed
