850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage

Name: 850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage
Brand: Olycom
Price: 1 USD

Wholesale 850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage from china suppliers

Brand Name : Olycom

Model Number : TA343-PSE-GE

Certification : CE RoHS FCC

Place of Origin : Shenzhen, China

MOQ : 1 Pcs

Price : Negotiable

Payment Terms : T/T, Paypal

Supply Ability : 1500 Pcs per week

Delivery Time : 3~7 working days

Packaging Details : 1 piece in 1 carton. 0.5KG/pcs

Product name : POE media converter Ethernet to fiber

Fiber : LC, SC/ST/FC optional

Transmission rate : 10/100/1000Mbps

Wavelength : 850nm/1310nm/1550nm

PoE pin : 1/2 (V+),3/6 (V-)

Dimension : 135mm(L) x 90mm(W) x 28mm(H)

Weight : Net weight: 0.3kg

Warranty : 1 year

Contact Now

Gigabit PoE Fiber Optic Media Converter

Product Introduction

Olycom 10/100/1000Mbps POE PSE PD Ethernet to fiber media converter features below

IEEE 802.3af/at Power Sourcing Ethernet (PSE) functionality on the twisted pair port
Supplying both data and electric current to devices
Widely used in WiFi access points, VoIP phones and IP security cameras
Unique premium aluminum compact case

Key Features

1 x 10/100/1000Base-TX port for data and power
External power supply
1 x 1000Base-FX or SX fiber port
Support AVB
Link fault pass through (LFPT)
IEEE802.3af/at compliant

Technical Parameters

Standard	IEEE802.3(10Mbps), IEEE802.3u (100Mbps), IEEE802.3z(1000Mbps), IEEE802.3x (Flow Control), IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree, IEEE802.3af PoE/PSE
10/100/1000BASE-T	STP or UTP Category 5/5e/6 cable (Max. 100m)
1000BASE-FX	50/125um(1Km), 62.5/125um MMF (550m), 9/125um SMF (20/40/60/80/100km)
Conversion Mode Delay Time	Store-and-Forward < 10us Straight-through<0.9us
Flow control	Full duplex-flow control, Half duplex-back pressure
RJ-45 Port	Auto-MDI/MDIX

Fiber Connector	LC standard, SC/FC optional
Wavelength	1310/1550nm
Input Voltage	48VDC/1A external power supply
Power Consumption	<2.5W
PoE pin assignment	1/2 (V+),3/6 (V-)
PoE Output	-48V, 0.54A, 25W
MTBF	50,000 hours
BER	<1/1000000000

MAC Address Table	4K
Buffer Size	1.75M
Operation Temperature	0℃~50℃
Storage Temperature	-20℃~85℃
Storage Humidity	5%~90% non-condescending
Dimensions and Weight	135mm(L) x 90mm(W) x 28mm(H) Net weight : 0.3kg, Gross weight : 0.5kg

Application

Schools, Offices, Cyber bars
FTTX Projects

850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage

Telecommunication Networks

850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage

Ordering Details

TA343-PSE-GE	PSE/PoE fiber media converter, 10/100/1000Mbps, single port, 220VAC in -48VDC out, 25W, without SFP module
TA343-PSE-GE/ M05-LC	PSE/PoE fiber media converter, 10/100/1000Mbps , single port, 220VAC in -48VDC out, 25W, MMF, dual fiber, 1310nm, 550M, LC
TA543-PSE-GE/ S20- SC	PSE/PoE fiber media converter, 10/100/1000Mbps , single port, 220VAC in -48VDC out, 25W, SMF, single fiber, 1310nm / 1550nm, 20Km, SC

850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage

Product Images

850nm Fiber Optic PoE Media Converter Gigabit Network Unmanaged Multimode SFP Cage
