60W Unmanaged Network Switch 6 Port 10/100M LAN Ports AC Input 250-Meter PoE

  • 1
  • 2
  • 3

Brand Name : OLYCOM

Model Number : OM706-PSE-FE

Certification : CE, RoHS, FCC

Place of Origin : Shenzhen, China

MOQ : 1 piece

Price : Negotiable

Payment Terms : T/T, PayPal

Supply Ability : 4000 sets per month

Delivery Time : 3~5 working days

Packaging Details : Neutral packing, 1 piece in a box

Name : POE Network Switch

Ports : 2 Uplink Ports and 4 RJ45 ports

Color : Black

Network Port : RJ45

PoE Standard : AF/AT

PoE Distance : 100m or 250m

Power Adapter Voltage : AC 110V-240V

Switching Capacity : 1.2Gbps

Contact Now

4*10/ 100Mbps PoE Switch Unmanaged
Introduction of Commercial Ethernet Switch
  • OLYCOM OM706-PSE-FE series PoE switch is designed by OLYCOM for meeting the demand of PoE power supply.
  • It adopts the latest high-speed Ethernet switching chip and ultra-high backplane bandwidth design, with extremely fast data processing capability to improve smooth data transmission performance.
  • It has 4 Poe-powered RJ45 ports and 2 RJ45 uplink ports. All of four RJ45 ports support IEEE 802.3af/at standard, with a maximum power supply of 30W for a single port and 78W for the whole machine, which can automatically detect and identify the powered devices that comply with IEEE 802.3af/at standard and supply power for the priority mechanism through the network cable.
  • With simple and convenient installation and maintenance means and rich service features, it helps users to build a safe and reliable high-performance network.
  • It is mainly positioned at the core or convergence layer of user networks such as industrial parks, buildings, factories and mines, government agencies, and community broadband. ,
  • It can be widely used in Ethernet access scenarios such as SMEs, Internet cafes, hotels, and schools.

Key Features of 10/100M LAN Switch

  • 4*10/ 100Mbps PoE ports, 2*10/ 100Mbps uplink port
  • Support IEEE802.3af/at
  • Support restrain network storm, VLAN function
  • Support Max Transmission distance up to 250m
  • All ports supported by MDI/ MDIX auto flip and self-negotiation
  • Built-in power supply
  • Maximum power of single PoE port : 30W
  • Whole machine power: 65W&78W
  • Adopts store-and-forward architecture
  • Fan-less, natural cooling, small, compact and quiet design ,suitable for desktop or wall
  • Support lightning protection 6kV


Specification of 4 Port PoE Switch

Power Power Adapter Voltage AC 110V-240V
Consumption 65W/78W

Network Connector

 Network Port PoE Ethernet Port 1~4 Port : 10/ 100Mbps
Ethernet port Uplink Port : 10/ 100Mbps
Transmission Distance

1~4 Port :
100Mbps:0~100m;
10Mbps: 0~250m;
Uplink Port : 0 ~ 100m
Transmission Medium Cat5/5e/6 standard network cable

Network Switch

 Network Standard

IEEE802.3/802.3u,
IEEE802.3x,
IEEE802.ab
Switching Capacity 1.2Gbps
Packet Buffer Memory 1Mbits
Throughput 0.8928Mpps
MAC Table 1K
Packet Forwarding rate

10Mbps:14880pps/port
100Mbps: 148800pps/port
Power Over Ethernet PoE Standard IEEE 802.3af/at
PoE Power Supply 12 45 + ,36 78- , 8 core power supply
PoE Power af=15.4W,at=30W for each port
RJ45 port Port Function

Power priority mechanism,
fast and forward,
MAC automatic learning and aging IEEE802.3X Full-duplex and mode and back-pressure for Half-duplex mode
LED Indicator LED Indicator

LINK/ACT.100Mbps;
PoE Status Indicator;
Power indicator;Extender
Environmental Working temperature 0C~55C
Relative Humidity 20~95%
Storage temperature -20C~70C
Mechanical Dimension (L ×W × H) 220mm*140mm*45mm
Color Black
Weight 0.95kg

Application of Unmanaged Network Switch

60W Unmanaged Network Switch 6 Port 10/100M LAN Ports AC Input 250-Meter PoE


Order Details of Unmanaged Switch

OM706-PSE-FE PSE/PoE network switch, 10/100Mbps, 6UTP , 4UTP with POE, 48VDC, 100m
OM714-PSE-FE/S20-SC PSE/PoE fiber switch, 10/100Mbps, 1 fiber to 4 UTP, 48VDC, SMF, dual fiber, 20Km, SC
OM714-PSE-FE/S40-SC PSE/PoE fiber switch, 10/100Mbps, 1 fiber to 4 UTP, 48VDC, SMF, dual fiber, 40Km, SC
OM714-PSE-FE/S60-SC PSE/PoE fiber switch, 10/100Mbps, 1 fiber to 4 UTP, 48VDC, SMF, dual fiber, 60Km, SC
OM714-PSE-FE/S80-SC PSE/PoE fiber switch, 10/100Mbps, 1 fiber to 4 UTP, 48VDC, SMF, dual fiber, 80Km, SC
OM714S/U-PSE-FE/S20-SC PSE/PoE fiber switch, 10/100Mbps, 1 fiber to 4 UTP, 48VDC, SMF, single fiber, 20Km, SC

60W Unmanaged Network Switch 6 Port 10/100M LAN Ports AC Input 250-Meter PoE
