4 Port PoE Af/At Gigabit Fiber Switch With 1 SFP/Copper Uplink Commercial Grade 60W

  • 1
  • 2
  • 3

Brand Name : Olycom

Model Number : OM154-PSE-GE

Certification : CE RoHS FCC ISO9001

Place of Origin : Shenzhen, China

MOQ : 1pc

Price : negotiable

Payment Terms : T/T, PayPal

Supply Ability : 2000pcs/month

Delivery Time : 3~7 working days

Packaging Details : 1 piece in a box, 930g G.W.

Product name : 4 port CCTV POE switch

PoE budget : 60W

Speed : 10/100/1000Mbps

Power Input : AC input, 100V~240V

Dimension : 200*118*44.5mm

Weight : 0.63kg

Contact Now

4 port Gigabit CCTV POE Switch

Description of Commercial Fiber Switch

  1. This 6-Port Gigabit PoE switch uses high-quality high-speed network IC and the most stable PoE chip
  2. The PoE port meets the 802.3af or 802.3at standard
  3. This series of PoE switches can provide seamless connection for 10/100/1000M Ethernet, and the PoE power supply port can automatically detect and supply power to powered devices that comply with IEEE802.3af or IEEE802.3at standards, and non-PoE devices intelligently detect no power supply, only data is transferred.

Technical Data of Gigabit Network Switch

I/O Interface
Power Input: AC 100-240V, 50/60Hz
Ethernet

4*10/100/1000M PoE Port

1*1000M RJ45 Port

1* Gigabit SFP Uplink Port
Performance
Switching Capacity 12Gbps
Throughput 8.928Mpps
Packet Buffer 1Mbit
MAC Address 2K
Jumbo Frame 9216bytes
Transfer Mode Store and forward
MTBF 100000 hour
Standard
Network protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX)

IEEE802.3ab(1000Base-TX)

IEEE802.3z(1000Base-FX)

IEEE802.3x (Flow control)

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

Network Medium

10Base-T : Cat3,4,5 or above UTP(≤100m)

100Base-TX : Cat5 or above UTP(≤100m)

1000Base-TX : Cat5 or above UTP(≤100m)
Optical Media

Multimode fiber : 50/125, 62.5/125, 100/140μm

Single-mode fiber: 8/125, 8.7/125, 9/125, 10/125μm
Protection
Certificate CE, FCC, RoHS
Environment
Working Environment

Working Temperature:-10~50°C

Storage Temperature:-40~70°C

Working Humidity :10%~90%,non-condensing

Storage Temperature:5%~95%,non-condensing
Indication
PWR(power supply)

Lighting: Powered

Un-Light: No Power
Mode(DIP)

Lighting: VLAN

Un-Light: Default

Flashing: Extend
1-6 Gree(Link&Data)

Lighting:C onnecting

Flashing: Data Transmit

Un-Light: Disconnect
DIP Switch

VLAN: Port isolation mode. In this mode, the PoE ports (1-4) of the switch cannot communicate with each other, and can only communicate with the UP-link port.

Default: Normal mode, all ports can communicate with each other, the transmission distance is within 100 meters

Extend: Link extension mode, 3-4 ports PoE power supply and data transmission distance can be extended to 250 meters, the transmission rate becomes 10M
Mechanical
Structure Size

Product Dimension: 200*118*44.5mm

Package Dimension: 245*190*60mm

N.W:0.63kg

G.W:0.93kg
Packing Info

Carton MEAS:520*320*400mm

Packing Qty:20units

Packing Weight:19.6KG
Power Voltage

Input Voltage: AC 100-240 V

Power supply:52V1.25A
power

Product power: maximum 5W

POE power: maximum 60W
Package List Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification 1 pc,

Features of 60W PoE Switch

  • 4*10/100/1000M POE Ports + 1*1000M RJ45 Port+1*1000M SFP Port
  • Comply with IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z standards
  • Ethernet port 10/100/1000M rate auto adaptive
  • Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard
  • Support Port Auto-flip (Auto MDI/MDIX)
  • Panel indicators to monitor working status and help fault analysis
  • One-key smart switch, supports VLAN, Default, Extend

Application Diagram

4 Port PoE Af/At Gigabit Fiber Switch With 1 SFP/Copper Uplink Commercial Grade 60W

  • Multimedia transmission: Integrated transmission of images, voice and data, suitable for remote teaching, conference TV, videophone and other applications
  • Real-time monitoring: Simultaneous transmission of real-time control signals, images and data
