24 Port 10/100M PoE Switch Gigabit Fiber Optic Uplink AC Rack Unmanaged 300W Budget

Name: 24 Port 10100M PoE Switch Gigabit Fiber Optic Uplink AC Rack Unmanaged 300W Budget
Brand: Olycom
Price: 1 USD

Wholesale 24 Port 10/100M PoE Switch Gigabit Fiber Optic Uplink AC Rack Unmanaged 300W Budget from china suppliers

Brand Name : Olycom

Model Number : OM12624G-PSE-FE

Certification : CE RoHS FCC ISO9001

Place of Origin : Shenzhen, China

MOQ : 1pc

Price : negotiable

Payment Terms : T/T, PayPal

Supply Ability : 2000pcs/month

Delivery Time : 5~8 working days

Packaging Details : 1 piece in a box, 2.4kg

Product name : 24 port fast Ethernet poe switch

Feature : Unmanaged, Rack type

Uplink : 3 ports, SFP and Copper

Power input : AC input

POE budget : 300W

POE distance : 100 meters

Contact Now

24 port unmanaged fast Ethernet CCTV PoE switch

Introduction to 24 port PoE switch

27 Port Gigabit Uplink 24 Port 100M PoE Switch enjoys below features

using high-quality high-speed network IC and the most stable PoE chip
PoE Port supporting both 802.3af and 802.3at standard
providing a seamless connection with 10/100M Ethernet
Automatically detect and power the powered devices that comply with the IEEE802.3af or IEEE802.3at standards

Features of 24 port Rack Switch

24*10/100M POE ports + 2* 10/100/1000M Ethernet Uplink ports+1* Gigabit SFP Uplink Port
Comply with IEEE 802.3, IEEE 802.3u, IEEE802.3ab ,IEEE802.3z IEEE802.3x standards
Ethernet port supports 10/100M adaptive
Support port auto flip (Auto MDI/MDIX)
Automatically supplied to adaptive devices
Panel indicator monitoring status and help failure analysis
Support for VLAN mode, OFF mode and Extend mode
Compatible with 1 U rack installation

Technical Information of PoE Fiber Switch

I/O Interface
Power	Input: AC 100-240V, 50/60Hz
Ethernet	24 10/100M PoE Port 2 10/100/1000M Ethernet Uplink ports 1* Gigabit SFP Uplink Port
Performance
Switching Capacity	10.8Gbps
Throughput	8.035Mpps
Packet Buffer	1.5Mbit
MAC Address	2K
Jumbo Frame	9216bytes
Transfer Mode	Store and forward
MTBF	100000 hour
Standard
Network protocol	IEEE802.3 (10Base-T) IEEE802.3u (100Base-TX) IEEE802.3ab(1000Base-TX) IEEE802.3z(1000Base-FX) IEEE802.3x (Flow control)
PoE Protocol	IEEE802.3af (15.4W) IEEE802.3at (30W)
Network Medium	10Base-T : Cat3,4,5 or above UTP(≤100m) 100Base-TX : Cat5 or above UTP(≤100m) 1000Base-TX : Cat5 or above UTP(≤100m)
Optical Media	Multimode fiber : 50/125, 62.5/125, 100/140μm Single mode fiber: 8/125, 8.7/125, 9/125, 10/125μm
Security Certificate	CE, FCC, RoHS
Environment
Working Environment	Working Temperature: -10~50°C Storage Temperature: -40~70°C Working Humidity: 10%~90%,non-condensing Storage Temperature: 5%~95%,non-condensing
Indication
LED Indicators	PWR(power supply),SW(DIP),1-27 Green(Link&Data)
PWR	Lighting: Powered Un-Light: No Power
SW	Lighting: VLAN Un-Light: OFF Flashing: Extend
1-27 Green	Lighting: Connecting Flashing: Data Transmit Un-Light: Disconnect
DIP Switch	VLAN, OFF, Extend
VLAN	Port isolation mode. In this mode, the PoE ports (1-24) of the switch cannot communicate with each other, and can only communicate with the UP-link port.
OFF	Normal mode, all port can communicate with each other, the transmission distance is within 100 meters, the transmission rate is 10M / 100M adaptive
Extend	Link extension mode, 9-24 ports PoE power supply and data transmission distance can be extended to 250 meters, the transmission rate becomes 10M
Mechanical
Structure Size	Product Dimension: 32020745mm Package Dimension: 37029085mm N.W:1.79kg G.W:2.40kg
Packing Info	Carton MEAS:445310390mm Packing Qty:5 units Packing Weight:12.77KG
Power Voltage	Input Voltage: AC 100-240 V Power supply: 52V5.76A
Power	Product power: maximum 15W POE power: maximum 280W
Package List	Switch 1 pcs, Power cord 1 pcs, User manual 1 pcs, Certification 1 pcs, Brackets 1 pair
